Photovoltaic modules are made of high-efficiency monocrystalline silicon solar cells through high-density encapsulation. They feature high efficiency, high power, low attenuation, high reliability, high stability, resistance to wind and hail, etc. The products are diversified and multi-specialized, suitable for different application scenarios and can meet various needs of customers.
Photovoltaic modules, also known as solar panels, have a sealed and internally connected structure and can independently provide direct current output. They are the smallest indivisible photovoltaic cell devices in the solar power generation system and the core part of the system. When sunlight shines on the surface of the photovoltaic module, the energy of the photons will excite the electrons in the semiconductor, and generate electricity in the form of current. This electricity can be used directly or stored in battery devices for later use.
The new generation of monocrystalline silicon photovoltaic cells adopts multi-busbar technology, which has better light utilization and current collection capabilities, and the power output of the modules is more stable and reliable, and can reduce the risk brought by microcracks and hot spots. The product has a long service life, strong installation adaptability, and the ability to withstand wind, hail and sandstorms. Its low voltage temperature coefficient allows for higher power output at high temperatures, and its excellent linearity and mechanical properties are suitable for various application scenarios of customers. It is suitable for environments such as low temperature, high altitude, desert and ice and snow.
| Model | Maximum Power Wp (W) | Maximum Working Voltage Vmpp (V) | Maximum Working Current Im (A) | Open Circuit Voltage Voc (V) | Short Circuit Current Isc (A) | Component Size W×L×H (mm) |
|---|
| CHT20-36M | 20 | 18.1 | 1.11 | 20.16 | 1.15 | 400×358×25 | | CHT30-36M | 30 | 18 | 1.67 | 21.92 | 1.78 | 520×410×25 | | CHT40-36M | 40 | 18.1 | 2.22 | 21.92 | 2.37 | 540×510×25 | | CHT60-36M | 60 | 18.1 | 3.32 | 21.72 | 3.48 | 660×530×25 | | CHT80-36M | 80 | 18 | 4.44 | 21.92 | 4.75 | 700×670×25 | | CHT100-36M | 100 | 18.1 | 5.53 | 21.72 | 5.8 | 770×660×25 | | CHT100-60M | 100 | 36.2 | 2.77 | 44.5 | 2.92 | 770×660×25 | | CHT120-36M | 120 | 18 | 6.67 | 21.72 | 7.18 | 1010×700×30 | | CHT150-36M | 150 | 18.5 | 8.15 | 22.71 | 8.52 | 1200×670×35 | | CHT200-36M | 200 | 23.01 | 8.7 | 26.9 | 9.14 | 1480×680×35 | | CHT250-60M | 250 | 38.2 | 6.55 | 45.84 | 7.08 | 1350×992×35 | | CHT300-60M | 300 | 35.8 | 8.38 | 42.96 | 9.07 | 1780×880×35 | | CHT320-60M | 320 | 37.6 | 8.52 | 45.12 | 9.21 | 1880×880×35 | | CHT400-72H | 400 | 31 | 12.91 | 37.2 | 13.7 | 1722×1134×35 | | CHT450-72H | 450 | 34 | 10.84 | 49.7 | 11.36 | 1909×1134×35 | | CHT550-72H | 550 | 41.76 | 13.18 | 49.87 | 13.96 | 2297×1134×35 | | CHT660-72H | 660 | 38.2 | 18.28 | 45.6 | 18.34 | 2384×1303×35 |
STC (Standard Test Conditions): 1000W/m², 25°C, AM 1.5 NOCT (Nominal Operating Cell Temperature): 800W/m², 20°C, AM 1.5, Wind Speed 1m/s Power Tolerance: -0/+3%
|
