Diesel generator set

15kW

WEICHAI

WP2.3D25E200

BMQW-15

1

Diesel generator set

15kW

SDEC

4Z2.7-G21

BMQW-15

1

Configuration   of each set

radiator

                       standard with a   50 degree water tank

included

battery

Maintenance free lead-acid acid

included

 control system

Self starting control（SmartGen original�?/span>

included

Wooden case package

included

included

Air circuit breaker

standard

included

base

standard

included

Transformer to battery connection wire

standard

included

shock pad

standard

included

model

BM15GF

(KVA/KW)

Rated output power (KVA/KW)

18.75/15

(A)       Rated output current (A)

27

(Hz)Frequency (Hz)

50

Output voltage

230V

Power factor

0.8 lag

generator weight (kg)

1500

Silent box size   (length * width * height) (mm)

1550*740*1100 about

Main parameters of the engine

model

WP2.3D25E200/4Z2.7-G21

type

In   line, water-cooled, four stroke

Air Intake method

Naturally aspirated

Total   displacement (L)

2.3/2.7

Cylinder   - Bore x stroke (mm)

4-89×92/4-90×105

Prime Power

23/22

Standby Power

25/24

Speed (r/min)

1500

Compression ratio

17.5:1

start mode

Electric   start

control mode

electronic   speed control

Main parameters of the alternator

model

BMQW-15

power(KVA/KW)

18.75/15

protection grade

IP23

Insulation level

H

Power factor

0.8 lag

Voltage fluctuation rate (%)

≤�?.5

Rated voltage (V)

230V

Adjustment range of no-load voltage

≥�?%

Voltage control mode

AVR

Efficiency   (%)

98.6

Connection

Three-phase four-wire
